Colorlight AX6K AI Media Station for LED Displays
$ 900.00
Colorlight AX6K is an Android 13 AI media station for wireless screen casting, presentations and video playback. It supports up to 8K decoding, HDMI and USB-C video outputs, and LAN/WiFi management. Whiteboard and sixteen-screen casting activation are optional.
10000 in stock
Colorlight AX6K AI Media Station for Meeting Displays
The Colorlight AX6K is an Android 13 media station for presentations, wireless screen casting and video playback. It connects media sources and meeting peripherals to a display system, with picture-in-picture and picture-by-picture layouts for sharing content in classrooms, conference rooms and exhibition spaces.
For an indoor LED display project, check the display controller and signal connections before ordering. The AX6K provides HDMI and USB-C DP Alt Mode video outputs; its Gigabit Ethernet connection is for network access and management.
Presentation and Playback Features
- Decode video up to 8K, with support for H.264, H.265, AV1, VP9 and AVS2. Decoding resolution is separate from the output timing.
- Present documents and play files from internal storage or a USB drive, using the built-in file manager.
- Share screens wirelessly and annotate content using compatible touch hardware. Third-party Android apps can be installed for meeting workflows.
- Use LAN or WiFi for network management, with control through WebUI, PlayerMaster, ColorlightCloudCMS or LED Assistant.
- Connect meeting cameras, microphones, a mouse or keyboard as required by the application. Online meetings require third-party meeting software.
AX6K Specifications
| Parameter | Specification |
|---|---|
| Operating system | Android 13 |
| Processor | 8-core chip; 8 nm process |
| Memory / storage | 8 GB DDR / 128 GB eMMC |
| HDMI IN 1 | HDMI 2.0; up to 3840 × 2160 at 60 Hz, YUV444 |
| HDMI IN 2 | HDMI 1.4; up to 3840 × 2160 at 30 Hz, YUV444 |
| Video outputs | 1 × HDMI output and 1 × USB-C DP Alt Mode output |
| HDMI output timing | 3840 × 2160 at 60 Hz, YUV444, as listed in the rear-panel table |
| Network connection | Gigabit Ethernet; WiFi 6, dual-band AP/STA |
| Bluetooth | Bluetooth 5.2 |
| Audio outputs | 1 × 3.5 mm audio jack; 1 × SPDIF |
| Power supply | DC 12 V / 3 A |
| Power consumption | 28 W |
| Operating temperature | −20°C to +60°C |
| Operating humidity | 0%–85% RH, non-condensing |
Specification note: The V1.0 document labels the HDMI output as HDMI 2.1 in its rear-panel table and system features, but HDMI 2.0 in its connectivity overview. Confirm the supplied hardware revision if the HDMI version is critical to your installation.
Options to Check Before Ordering
The specification lists single-screen wireless casting as standard. Sixteen-screen casting and the whiteboard feature require separately purchased activation codes. Physical 2K and 4K screen-casting dongles are also optional. Automatic brightness adjustment requires an optional ambient-light sensor.
Frequently Asked Questions
Is the AX6K a complete LED display?
No. It is an AI media station used with a display system. Check the video input requirements of your display controller and the required connection cables.
Does 8K video decoding mean 8K HDMI output?
No. The specification lists up to 8K decoding separately from the HDMI output timing of 3840 × 2160 at 60 Hz. Plan the signal path using the required output timing.
Can I cast multiple screens wirelessly?
Single-screen casting is supported by default. The specification lists a separate activation code for sixteen-screen wireless casting.
Is the electronic whiteboard included as standard?
The specification lists a separate whiteboard activation code. Compatible touch hardware is also needed for touch interaction.
Can the AX6K run video meetings and Android apps?
Yes. It runs Android 13 and supports third-party app installation. Meeting use requires suitable third-party software and compatible cameras, microphones or other peripherals.
Product Images and Specification Download
Download Specification:
Colorlight AX6K LED Display AI Media Station Specification
| Weight | 3.5 kg |
|---|
