Colorlight A100 LED Cloud Player – 1.3 Million Pixels
Price range: $ 284.00 through $ 404.00
Colorlight A100 LED cloud player with 1.3-million-pixel capacity, HDMI input/output and two LED output ports. Supports synchronous and asynchronous playback; V3.2 lists 25 GB usable storage.
Colorlight A100 LED Display Cloud Player
The Colorlight A100 combines synchronous HDMI input and asynchronous program playback for LED displays up to 1.3 million pixels. Two Ethernet outputs connect to receiving cards, while HDMI output supports up to 1920 × 1200 at 60 Hz. The linked V3.2 specification lists 32 GB storage with 25 GB available for content.
Managing Everyday Display Content
Prepare programs in PlayerMaster and arrange video, images, text, clocks and web content in adjustable windows. The A100 supports scheduled playback, up to 32 program pages and USB drive updates. Its video processing supports one 4K, two 1080p or four 720p windows; LED output capacity remains 1.3 million pixels.
Connect by LAN or 2.4 GHz Wi-Fi for network management. Wi-Fi supports hotspot and client modes, with optional 4G for mobile networking and optional GPS positioning. NTP synchronization supports coordinated screen playback. Synchronous and asynchronous priority settings let an installation select how live input and stored programs are used.
External sensors connect through two RJ11 ports for environmental monitoring and automatic brightness adjustment. Select sensors according to the measurements required at the display.
Technical Specifications
Based on the linked Colorlight A100 specification V3.2. Maximum width and height are separate limits within the total loading capacity.
| Parameter | Specification |
|---|---|
| LED loading capacity | Up to 1.3 million pixels |
| Maximum width / height | 4,096 pixels / 2,560 pixels |
| HDMI output | Up to 1920 × 1200 at 60 Hz |
| Playback modes | Synchronous input display; asynchronous playback; priority selection |
| Video processing | 4K H.265/H.264 hardware decoding; VP9 decoding |
| Video window combinations | 1 × 4K, 2 × 1080p, or 4 × 720p |
| Storage | 32 GB total; 25 GB available |
| LED outputs | 2 × Ethernet outputs to Colorlight receiving cards |
| HDMI ports | HDMI IN and HDMI OUT |
| Network | LAN; 2.4 GHz Wi-Fi hotspot/client; optional 4G |
| USB | USB 3.0 for flash drive or camera; USB-B CONFIG |
| Other interfaces | 3.5 mm stereo output; 2 × RJ11 sensor ports; Micro-SIM slot |
| Optional positioning | GPS |
| Dimensions (W × H × D) | 234.8 × 26.0 × 137.4 mm |
| Net weight | 0.83 kg |
| Power input / rated power | DC 12 V / 12 W |
Frequently Asked Questions
What is the Colorlight A100 loading capacity?
The A100 supports up to 1.3 million LED pixels. Maximum width is 4,096 pixels and maximum height is 2,560 pixels, within the overall capacity.
How much storage is available on the A100?
The linked V3.2 specification lists 32 GB installed storage with 25 GB available for content.
Can A100 play live HDMI and stored programs?
Yes. It supports synchronous HDMI input and asynchronous playback, with priority settings for the two modes.
Does A100 require an internet connection for every update?
No. USB flash-drive program updates and playback are supported. LAN and Wi-Fi are also available for network management.
Does A100 output 4K video?
4K refers to its decoding capability. The listed HDMI output is up to 1920 × 1200 at 60 Hz, and the LED loading capacity is 1.3 million pixels.
