Colorlight AX08 LED Media Station | 8-Port, 5.2M Pixels
$ 1,010.00
Colorlight AX08 is an Android 13 LED media station with eight Gigabit Ethernet outputs and a 5.2-million-pixel load. It combines live HDMI input, local media playback and wireless casting for presentation screens. Multi-screen casting and whiteboard activation are optional.
10000 in stock
Colorlight AX08 LED Media Station for Presentations
The Colorlight AX08 combines Android 13 media playback with synchronous and asynchronous LED sending. Its eight Gigabit Ethernet outputs support a total load of up to 5.2 million pixels, making it suitable for presentation screens in meeting rooms, classrooms and exhibition spaces.
Use HDMI sources for live content or play documents, images and video from storage. Wireless screen casting, picture-in-picture and picture-by-picture layouts support collaborative presentations. Third-party meeting apps and compatible cameras or microphones are required for online meetings.
Display and Control Features
- Up to 8K video decoding with H.264, H.265, AV1, VP9 and AVS2 support. The decoding limit is separate from the LED pixel load and HDMI output resolution.
- Android app installation, USB media playback and a built-in file manager for local content.
- LAN/WiFi management with WebUI, PlayerMaster, ColorlightCloudCMS and LED Assistant control options.
- Infrared/Bluetooth remote control and support for compatible touch frames. Automatic brightness adjustment requires an optional ambient-light sensor.
AX08 Technical Specifications
| Parameter | Specification |
|---|---|
| LED outputs | 8 × Gigabit Ethernet |
| Maximum LED load | 5.2 million pixels |
| Maximum screen width | 7680 pixels, within the total pixel-load limit |
| Operating system | Android 13 |
| DDR / eMMC | 8 GB / 128 GB |
| HDMI IN 1 | HDMI 2.0; 3840 × 2160 at 60 Hz, YUV444 |
| HDMI IN 2 | HDMI 1.4; 3840 × 2160 at 30 Hz, YUV444 |
| HDMI output | 1 × HDMI 2.0; 3840 × 2160 at 60 Hz, YUV444 |
| Additional video output | 1 × USB-C DP Alt Mode |
| Network management | Separate Gigabit Ethernet connection; WiFi 6, dual-band AP/STA |
| Bluetooth | 5.2 |
| Power supply / consumption | DC 12 V / 3 A; 28 W |
Check Optional Functions
The linked specification lists single-screen wireless casting as standard. Nine-screen casting and electronic whiteboard use require separate activation codes. Physical 2K USB-A and 4K USB-C casting dongles are listed as optional accessories. Confirm the required activations and peripherals for your installation.
Frequently Asked Questions
How many pixels can the Colorlight AX08 control?
The AX08 supports a total LED load of up to 5.2 million pixels across eight Gigabit Ethernet outputs. The linked V1.6 specification lists a maximum width of 7680 pixels; total pixel load must still remain within the limit.
Does the AX08 support live input and standalone playback?
Yes. It provides synchronous and asynchronous sending functions, HDMI inputs and local media playback from storage or a USB drive.
Is 8K decoding the same as an 8K LED screen load?
No. Video decoding, HDMI output timing and LED pixel capacity are separate limits. The AX08 specification lists up to 8K decoding, 3840 × 2160 at 60 Hz HDMI output and a 5.2-million-pixel LED load.
Are multi-screen casting and whiteboard functions included?
Single-screen wireless casting is standard in the linked V1.6 specification. Nine-screen casting and the whiteboard feature require separately purchased activation codes. Compatible touch hardware is needed for touch interaction.
Can I manage the AX08 over a network?
Yes. It supports LAN and WiFi management. The dedicated network-management Ethernet connection is separate from the eight outputs connected to LED receiving cards.
Product Images and Specification Download
Download Specification:
Colorlight AX08 LED Display AI Media Station Specification
| Weight | 3.5 kg |
|---|
