Sysolution E10 Android LED Controller with 3G, Wi-Fi and GPS
$ 287.69
The Sysolution E10 combines Android 4.4, 3G, Wi-Fi and GPS for connected LED signage. It supports AIPS publishing, local hotspot access and cascading. Check the layout note for non-cascaded screens, and use the linked manual for USB and Wi-Fi setup.
9998 in stock
E10 connected playback and local setup
The Sysolution E10 supports remote program publishing, status monitoring, screen scheduling and display logs through AIPS. Local Wi-Fi/AP operation and a mobile-app workflow provide another way to manage content. The listed media types include video, images, text, clocks, real-time messages and HTML content.
For an existing installation, verify the receiving cards and non-cascaded layout: the original page gives 320 × 256, while the manual gives 256 × 256; both give 540 × 960 after cascading. Storage is documented as 4 GB eMMC with TF expansion up to 32 GB, but the additional internal-memory wording differs. The FAQ below includes practical USB filename and Wi-Fi hotspot guidance from the manual.
Technical specifications
| Parameter | Specification |
|---|---|
| Model / system | Sysolution E10 Android wireless LED controller / Android 4.4 |
| Cascaded layout | 540 × 960 pixels, as listed in both sources |
| Non-cascaded layout | Original product table: 320 × 256; linked manual: 256 × 256. Confirm the applicable version. |
| Storage | 4 GB eMMC; Micro-SD/TF expansion up to 32 GB. Additional memory wording differs between listing and manual. |
| Gray levels / scans | 65,536; full-color static through 32-scan modules |
| 3G bands | WCDMA Band 1/8 (2100/900 MHz) |
| GSM bands | GSM 850, EGSM 900, DCS 1800 and PCS 1900 |
| Maximum cellular data rates | HSPA: 21 Mbps downlink, 5.76 Mbps uplink; EDGE: 236.8 Kbps; GPRS: 85.6 Kbps |
| Wi-Fi | 802.11b/g/n; Wi-Fi and SoftAP modes |
| Wi-Fi security / QoS | WPA/WPA2; WMM and WMM PS listed |
| GPS / AGPS | 1575.42 MHz; positioning support |
| GPS start times | Hot: less than 5 s; warm: less than 15 s; cold: less than 50 s, as specified |
| Cloud functions | AIPS remote publishing, status, power management, display logs and terminal grouping |
| Local configuration | LedSet 2.0; controller hotspot and mobile-app updates |
| Content types | Video, images, text, weather, clocks, countdown, real-time messages and HTML content |
| Video formats | 3GP and MP4; MPEG-4, H.263 and H.264 documented |
| Animation / images / text | GIF, SWF; BMP, JPG, GIF, WMF, ICO; TXT and RTF |
| Audio / microphone / camera | Supported in original product table |
| Receiving-card references | Manual lists D10-75 or D10; confirm the required configuration |
| Sensor / monitoring support | Brightness and cabinet monitoring; R30E sensor accessory described |
| Scheduling / synchronization | Timed programs, screen switching and multi-screen program synchronization |
| Power-loss feature | Up to 6 seconds of transient controller operation described; not a whole-screen backup-power rating |
| Working temperature | −30 to +70 °C, from original product table |
| Storage temperature | −40 to +90 °C, from original product table |
Product images and specification download
Download user manual:
Sysolution E10 Andriod Integrate 3G/GPS/WIFI Wireless Module Control Card Manual
Frequently asked questions
What screen resolution does E10 support with and without cascading?
Both the listing and manual give 540 × 960 after cascading. Without cascading, the listing says 320 × 256 and the manual says 256 × 256. Confirm the unit version and screen configuration before choosing a non-cascaded layout.
Why does the E10 fail to load a program from a USB drive?
The manual’s troubleshooting section says the exported archive must be named program.zip. Remove added filename suffixes such as “(15)” from the exported program archive before using the USB update workflow described in the manual.
Why can I no longer find the E10 Wi-Fi hotspot?
The manual says the hotspot can shut down in energy-saving mode after a long period without a connection. It suggests restarting the controller or resetting the Wi-Fi dial. Follow the manual’s AP-mode procedure and use the controller serial number to identify the hotspot.
Does E10 support 4G LTE?
The detailed radio parameters document GSM/GPRS/EDGE and WCDMA/HSPA+ on Bands 1/8. They do not establish LTE support for the supplied E10. Confirm the actual modem before relying on any mobile-network capability beyond those documented bands.
Does the six-second outage feature keep the entire LED display powered?
The documentation describes transient operation of the controller using its supercapacitor protection. It does not specify backup power for the LED modules, so it should not be treated as six seconds of whole-display battery backup.
