Colorlight A200 LED Cloud Player – HDMI & 2.3 Million Pixels
Price range: $ 388.00 through $ 508.00
Colorlight A200 LED player with synchronous HDMI and asynchronous playback, four LED outputs and 2.3-million-pixel capacity. V2.2 specifications list 32 GB storage with 25 GB available.
Colorlight A200 LED Cloud Media Player
The Colorlight A200 supports synchronous HDMI display and asynchronous program playback for LED screens up to 2.3 million pixels. It offers selectable playback priority, four Ethernet outputs to receiving cards and HDMI output up to 1920 × 1200 at 60 Hz. The V2.2 specification lists 32 GB of storage, with 25 GB available for content.
Live Input, Stored Programs and Cloud Management
Use HDMI input for synchronous content or publish stored programs through PlayerMaster. The player supports one 4K, two 1080p or four 720p video windows, together with images, text, clocks, web content and weather. Up to 32 program pages and scheduled commands support unattended display operation.
LAN and 2.4 GHz Wi-Fi provide network access, with optional 4G and GPS positioning. Wi-Fi supports hotspot and client modes. ColorlightCloud supports centralized publishing and player monitoring, while USB storage provides local playback and program updates. NTP synchronization supports coordinated playback across multiple screens.
Two sensor ports connect external sensors for automatic brightness adjustment and environmental monitoring. Confirm the sensor configuration required for the installation.
Technical Specifications
Parameters below follow the linked Colorlight A200 specification V2.2. Maximum width and height are separate limits within the total LED loading capacity.
| Parameter | Specification |
|---|---|
| LED loading capacity | Up to 2.3 million pixels |
| Maximum width / height | 4,096 pixels / 2,560 pixels |
| HDMI resolution | Up to 1920 × 1200 at 60 Hz |
| Playback modes | Synchronous display or asynchronous playback; configurable priority |
| Video decoding | 4K H.265/H.264 hardware decoding; 4K VP9 decoding |
| Video window combinations | 1 × 4K, 2 × 1080p, or 4 × 720p |
| Storage | 32 GB total; 25 GB available |
| LED outputs | 4 × Ethernet outputs to receiving cards |
| Video interfaces | HDMI IN; HDMI OUT for synchronous or asynchronous signal |
| Network | LAN; 2.4 GHz Wi-Fi hotspot/client; optional 4G |
| USB | USB 3.0 for flash drive/camera; USB-B CONFIG for PC setup or publishing |
| Audio / sensors | 3.5 mm stereo audio output; 2 × RJ11 sensor ports |
| Optional positioning | GPS |
| Dimensions (W × H × D) | 234.8 × 26.0 × 137.4 mm |
| Net weight | 0.83 kg |
| Power input / rated power | DC 12 V / 15 W |
Frequently Asked Questions
What is the Colorlight A200 pixel capacity?
The V2.2 specification lists up to 2.3 million pixels. Maximum width is 4,096 pixels and maximum height is 2,560 pixels, subject to the total capacity.
Can A200 switch between live HDMI and stored programs?
Yes. It supports synchronous display and asynchronous playback, with a priority setting for the two modes.
How much storage does the A200 V2.2 specification list?
It lists 32 GB total storage, with 25 GB available for content. This page follows the linked V2.2 document.
Does A200 support 4K output?
It supports 4K video decoding, while the specification lists HDMI up to 1920 × 1200 at 60 Hz and an LED load of 2.3 million pixels. Decoding resolution is different from output capacity.
Can A200 use Wi-Fi or a mobile network?
It supports 2.4 GHz Wi-Fi in hotspot or client mode and wired LAN. 4G networking is optional.
