Sysolution S40 2-in-1 LED Video Processor
$ 180.00
The Sysolution S40 combines video processing with integrated LED sending. Front-panel controls support screen setup and preset recall, while seamless switching and fade transitions manage multiple sources. Confirm the hardware version because the supplied document gives conflicting port-count and pixel-load information.
10000 in stock
Integrated video processing and front-panel LED setup
The Sysolution S40 is designed for LED display installations in shopping malls, hotels, exhibitions and similar venues. Its integrated sending function reduces the number of separate control devices, and the front-panel LCD, rotary knob and buttons provide direct access to screen settings. Eight user templates support repeat setups.
Hardware-version note: The original product text describes two Ethernet outputs. The linked PDF, internally marked Ver.1.1, also contains a later-version table with four outputs and inconsistent pixel-load wording. The table below identifies information from that document without treating the conflicting limits as confirmed. Verify the rear-panel layout and the specification for the unit being supplied.
Technical specifications
| Parameter | Specification |
|---|---|
| Model | Sysolution S40 2-in-1 LED video processor |
| Sending function | Integrated sending-card function |
| Ethernet outputs | Version check required: original listing and PDF introduction say 2; the PDF later-version interface table lists 4 |
| Pixel load | Requires confirmation: PDF function text states 2.3 megapixels, while its separate load table contains inconsistent numeric/unit wording |
| HDMI inputs, later-version table | 2 × HDMI 1.3; up to 1920 × 1080 at 60 Hz; HDCP 1.4 supported |
| DVI input, later-version table | 1; up to 1920 × 1080 at 60 Hz |
| VGA input, later-version table | 1; up to 1920 × 1080 at 60 Hz |
| CVBS input, later-version table | 1; PAL / NTSC |
| Audio | 1 × 3.5 mm audio input and 1 × 3.5 mm audio output |
| Control connections | 1 RS232 debugging port; 1 USB-B debugging port |
| Front-panel operation | LCD, rotary knob and buttons |
| User presets | 8 recallable user templates |
| Image control | Window position/size adjustment, cropping, custom output resolution and input EDID |
| Switching | Seamless switching or fade transitions; synchronized audio/video switching |
| Other functions | USB media playback, full/partial-screen switching, engineer lock and one-button blank screen |
| Power input / rated power | 100–240 VAC, 50/60 Hz / 11 W |
| Operating temperature | −20 to +70 °C |
| Operating humidity | 10–90% RH, non-condensing |
| Dimensions / net weight | 430 × 251 × 44 mm (L × W × H) / 3.85 kg |
Product images and specification download
Download specification:
Sysolution S40 LED Display Screen 2 In 1 Video Processor Specification
Frequently asked questions
Does the S40 need a separate sending card?
The S40 has an integrated sending-card function and connects to LED receiving cards through its Ethernet outputs. Confirm receiving-card compatibility and the output-port configuration of the supplied version.
Does the S40 have two or four Ethernet outputs?
The original listing and the PDF introduction say two, while the PDF later-version interface table lists four. The linked file is titled Ver.1.1 internally. Verify the hardware revision and rear-panel ports before ordering; the page cannot establish one port count for every S40.
What is the confirmed pixel capacity of this S40?
The supplied PDF is inconsistent: its function section says 2.3 megapixels, while the load table contains conflicting number and unit wording. Obtain the specification matching the supplied hardware and intended screen layout before relying on a maximum load.
Can I configure the screen from the front panel?
Yes. The S40 provides an LCD, knob and buttons for screen configuration without PC software. It also supports eight user templates that can be recalled for repeated setups.
Can the S40 switch video sources without a visible cut?
The specification lists seamless switching and fade-in/fade-out transitions between signal inputs, together with synchronized audio/video switching. Its later-version interface table lists HDMI, DVI, VGA and CVBS inputs.
