XingXiu DSP200V-5 LED Power Supply – 5V, 200W
$ 13.50
The XingXiu DSP200V-5 supplies 5V DC at 200W rated output. It accepts 90–264V AC input and uses an isolated LLC design with ventilation cooling in a 208 × 60 × 30mm case.
10000 in stock
200W, 5V power supply for LED display equipment
The XingXiu DSP200V-5 converts nominal 100–240V AC input to 5V DC. Its rated output power is 200W, and the LLC design provides isolation between the input and output.
The unit measures 208 × 60 × 30mm and uses ventilation cooling. For a new installation or replacement, compare the enclosure and connections with your cabinet layout, then check the complete electrical requirements in the downloadable specification.
Technical specifications
| Parameter | Specification |
|---|---|
| Model | XingXiu DSP200V-5 |
| DC output | 5 V |
| Rated output power | 200 W |
| Input voltage range | 90–264 V AC |
| Nominal input | 100–240 V AC |
| Frequency | 47–63 Hz |
| Maximum AC input current | 4 A at full load |
| Cold-start inrush current | Less than 120 A at 230 V AC |
| Full-load efficiency | At least 87% at 230 V AC |
| Leakage current | Less than 0.5 mA at 230 V AC |
| Input fuse | T5AL / 250 V AC |
| Power factor | Greater than 0.95 at 230 V AC, full load |
| Cooling | Ventilation cooling |
| Dimensions | 208 × 60 × 30 mm |
Product images and specification download
Download Specification:
XingXiu DSP200V-5 LED Power Supply Specification
Frequently asked questions
What output does the DSP200V-5 provide?
It provides 5V DC with a rated output power of 200W. Match these requirements to the LED display load and consult the PDF for full output specifications.
Is the DSP200V-5 suitable for both 110V and 230V AC input?
Both voltages are within its 100–240V AC nominal range. The specified full input range is 90–264V AC at 47–63Hz.
How large is this 200W power supply?
Its listed dimensions are 208 × 60 × 30mm. Confirm mounting and connector positions using the specification PDF rather than relying on case dimensions alone.
What efficiency is listed for this model?
The specified minimum efficiency is 87% at 230V AC and full load. The listed power factor is greater than 0.95 under the same input and load conditions.
| Weight | 0.5 kg |
|---|
