VDWall LVP615D HD LED Video Processor – DVI/VGA/HDMI Expansion
$ 480.00
VDWall LVP615D HD video processor with a DVI/VGA/HDMI extended input. Supports three PIP/PBP presets, AIAO cropping, custom output formats and DVI loop-through.
10000 in stock
Expanded input flexibility for LED screens
The VDWall LVP615D provides a DVI/VGA/HDMI extended input configuration alongside the main video inputs. It supports direct source switching or Preselect + TAKE, plus seamless, fade and blend transitions for presentation changes.
Three custom PIP/PBP modes support dual-image layouts. AIAO cropping selects the source area shown on screen, while editable DVI EDID and custom output formats help match the LED display. DVI loop-through supports synchronized multi-unit installations.
LVP615D specifications
These parameters follow the manufacturer’s LVP615D User Manual V1.2. Confirm the hardware revision supplied for your installation.
| Parameter | Specification |
|---|---|
| Main inputs | 2 × Video; 1 × YPbPr; 2 × VGA; 1 × DVI; 1 × HDMI; 1 × DP |
| Extended input | 1 × DVI/VGA/HDMI |
| Shared input | V2 / YPbPr: composite or component video |
| Outputs | 2 × DVI; 1 × VGA; DVI loop-through |
| Custom output limits | Width up to 3840 pixels or height up to 1920 pixels |
| VGA input | Up to 2048 × 1152 at 60Hz |
| DVI input | Up to 2304 × 1152 at 60Hz |
| HDMI / DP input | Up to 1920 × 1080 at 60Hz |
| Control | RS232 / USB / LAN / Wi-Fi / remote control |
| Input voltage | 100–240VAC, 50/60Hz |
| Power consumption | ≤25W |
| Temperature | 0–45°C |
| Humidity | 15–85% |
| Product size | 483 × 274 × 66.6 mm (L × W × H) |
| Weight | Net 4.2 kg; gross 5.7 kg |
Frequently asked questions
What is the extended input on the LVP615D?
The manufacturer’s LVP615D manual identifies a DVI/VGA/HDMI extended input. Confirm the connection required by your source before ordering.
Can the LVP615D show two sources together?
Yes. It supports PIP/PBP with three custom display modes and adjustable image cropping.
Are the two DVI outputs independent image channels?
The LVP615D manual describes DVI OUT1 and OUT2 as the same digital graphic signal. Plan the sending-card configuration accordingly.
Can the output be set to 3840 × 1920?
The listed custom width and height are separate maxima. Select a supported timing and confirm the required screen dimensions rather than combining the two limits.
Product images and specification download
| Weight | 7 kg |
|---|
