VDWall LVP100M HD LED Video Processor – Dual-Picture Layout
$ 99.00
VDWall LVP100M HD processor with Pa/Pb dual-picture layouts and preset scene recall. The listing and linked manual differ on output configuration; confirm the supplied unit before ordering.
986 in stock
Pa/Pb dual-picture layouts for LED screens
The VDWall LVP100M supports Pa and Pb image areas, with adjustable picture size and position for PIP/POP, tiled or overlaid layouts. Preset scenes and front-panel knob adjustment support repeatable setups for exhibition halls, advertising displays, meeting rooms and rental installations.
Configuration to confirm before ordering
The previous product description lists four RJ45 outputs and a 2.03-million-pixel load. The linked LVP100M User Manual V1.0 instead describes DVI output, an optional LED sender and a 2.65-million-pixel driving capability. These descriptions are not interchangeable. Confirm the rear-panel connections, sender configuration and supported output timing of the supplied unit.
Parameters documented in the LVP100M manual
| Parameter | Specification |
|---|---|
| Video inputs | 3 × HDMI 1.3; 1 × DVI |
| Input timing | Up to 1920 × 1080 at 60Hz |
| Video output | 1 × DVI |
| Audio output | Stereo, 3.5 mm |
| Control connection | USB communication |
| Input voltage | 100–240VAC, 50/60Hz |
| Maximum consumption | 11W |
| Ambient temperature | 0–40°C |
| Ambient humidity | 15–90% |
| Dimensions | 482.6 × 200 × 44 mm (L × W × H) |
| Weight | Net 2.5 kg; gross 4 kg |
Layout features
The product description lists 16 preset display scenes and seamless scene switching. The Pa/Pb picture areas can be positioned within the selected output resolution. Review the output timing list in the PDF before configuring an unusually wide or tall screen.
Frequently asked questions
Does the LVP100M have RJ45 or DVI output?
The listing and linked manual conflict on this point. Confirm the rear-panel photo and sender configuration of the supplied unit before ordering.
Can the LVP100M show two pictures together?
Yes. Pa/Pb dual-picture layouts support adjustable size and position for PIP/POP and tiled or overlaid display.
Can I use USB to play video files?
The linked manual identifies USB as a communication port. USB media playback is not established by that description.
Where can I find the output timings?
Use the retained LVP100M PDF downloads below. Confirm the output timing against the supplied hardware and connected LED sending equipment.
Product images and PDF documents
VDWALL LVP100M LED HD Processor Introduction
VDWALL LVP100M LED HD Processor Use Manual
| Weight | 5 kg |
|---|
