Colorlight X4m LED Video Controller with USB Media Playback
$ 195.00
Colorlight X4m combines USB picture/video playback with HDMI, DVI, VGA and CVBS inputs. Four Gigabit Ethernet outputs support up to 2.6 million pixels, with independent audio input/output and 16 scene presets.
2500 in stock
The Colorlight X4m is an LED video controller with USB flash-drive playback, HDMI/DVI/VGA/CVBS source inputs and four Gigabit Ethernet outputs. It supports up to 2.6 million pixels and accepts input signals up to 1920 × 1080 at 60 Hz.
Live inputs and USB media playback
Two HDMI 1.4 inputs, one DVI input, one VGA input and one CVBS input connect digital and analog video equipment. The USB media interface plays pictures and videos from a flash drive. Source switching, cropping, scaling and screen offset help fit content to the display.
Independent 3.5mm audio input and output are provided, along with HDMI and USB-media audio output support. Sixteen scene presets can be saved and recalled. USB and RS232 provide control, while infrared remote control is optional.
Colorlight X4m specifications
These values follow the linked X4m Specification V1.5.
| Parameter | Specification |
|---|---|
| Maximum input resolution | 1920 × 1080 at 60 Hz |
| HDMI inputs | 2 × HDMI 1.4 |
| Other video inputs | 1 × DVI, 1 × VGA, 1 × CVBS |
| USB media interface | 1; picture and video playback from a USB flash drive |
| LED outputs | 4 × Gigabit Ethernet |
| Maximum loading capacity | 2.6 million pixels |
| Maximum width | 3,840 pixels |
| Maximum height | 2,000 pixels |
| Backup | Ethernet port redundancy |
| Audio input | 1 × 3.5mm |
| Audio output | 1 × 3.5mm; HDMI and USB-media audio supported |
| Scene presets | 16 |
| Image processing | Switching, cropping, scaling and screen offset |
| Image adjustment | Contrast, saturation, hue, brightness compensation and sharpness |
| Input color range | Limited-range to full-range conversion |
| HDCP | HDCP 1.4 |
| Control | USB and RS232; optional infrared remote |
Configuration considerations
Check the display’s total pixel count as well as its width and height. The maximum dimensions do not mean a 3840 × 2000 screen fits within the 2.6-million-pixel capacity. Source input resolution is a separate limit.
Color management and calibration functions should be checked against the receiving-card model used in the LED cabinets. Confirm the optional remote if you need infrared control, and verify media compatibility before preparing USB playback content.
Frequently Asked Questions
Can the Colorlight X4m play video from a USB drive?
Yes. V1.5 lists playback of pictures and videos from a USB flash drive. Check supported media requirements in the specification before preparing playback files.
What is the maximum screen capacity of the X4m?
The total capacity is 2.6 million pixels, with maximum width 3,840 pixels and maximum height 2,000 pixels. All limits apply to the planned screen layout.
Which video inputs are available on the X4m?
The X4m has two HDMI 1.4 inputs, one DVI input, one VGA input and one CVBS input. The specified maximum input resolution is 1920 × 1080 at 60 Hz.
Does the X4m provide audio output?
Yes. It has independent 3.5mm audio input and output, and supports audio output from HDMI and USB media.
Is an infrared remote included as standard?
The V1.5 specification identifies infrared remote control as optional. Confirm the remote in the ordered configuration if it is needed.
Download the X4m specification
| Weight | 7 kg |
|---|
