4K media playback through HDMI
The VDWall MP905 provides a media source for an LED display system through its HDMI 2.0 output. It supports H.265 hardware decoding, local video and picture playback, and network playback. Match its HDMI output to the input of your display system or video processor.
Playback and operation
Play content from local flash storage, USB media or a memory card. Auto-play searches for video files in the flash root directory at startup or in the USB drive root directory when a drive is inserted. The player supports mouse and keyboard operation, PPT slideshows with a laser page pen, and Wi-Fi screen sharing from phones, tablets and computers.
MP905 specifications
| Parameter | Specification |
|---|---|
| Processor | Amlogic S905; 64-bit 4-core CPU; 3+2-core GPU |
| RAM | 1GB DDR3 |
| Storage | 8GB NAND |
| Listed output format | Ultra HD 4K HDR |
| Video decoding | H.265, H.264, MPEG-4, WMV, AVS, MPEG-2, MPEG-1, RealVideo |
| Listed file formats | mkv, wmv, mpg, mpeg, dat, avi, mov, iso, mp4, rm |
| Video output | 1 × HDMI 2.0 |
| USB | 2 × USB 2.0 |
| Wired network | 1 × RJ45 LAN, 10/100M |
| Wireless | Wi-Fi 802.11b/g/n, 2.4GHz; BT4.0 |
| Memory card slot | 1 × TF |
| Input voltage | 5VDC |
| Power | ≤10W |
| Temperature | 0–45°C |
| Humidity | 15–85% |
| Package dimensions | 249 × 206 × 55 mm (H × W × L) |
Frequently asked questions
Does the MP905 support H.265 video?
Yes. H.265 hardware decoding is one of its listed features. Match the file format and output settings to the receiving display equipment.
Can the MP905 play videos automatically from a USB drive?
Yes. When a USB drive is inserted, auto-play searches for video files in its root directory. Startup auto-play is also supported for the flash root directory.
How does the MP905 connect to a display system?
It provides one HDMI 2.0 output. Connect it to a compatible display or the HDMI input of the video processor used in the LED system.
Can I share a phone or computer screen over Wi-Fi?
The product description supports wireless screen sharing from phones, tablets and computers, along with Wi-Fi network access.
Product images and PDF download



VDWall MP905 4K Ultra HD LED Display Media Player specification
