Sysolution Y50 Asynchronous LED Display Controller
$ 121.00
The Sysolution Y50 is an asynchronous LED display controller for car, community, small traffic and light-pole screens. It supports Ethernet and Wi-Fi content updates, cloud management and optional regional 4G connectivity. The manual lists a 1280 × 720 LED display resolution.
10000 in stock
Remote content control for compact LED signage
The Sysolution Y50 lets users publish programs and manage LED displays from a PC, phone or tablet. Ethernet and onboard Wi-Fi support local or networked operation, while the AIPS cloud platform provides remote publishing, scheduling and group management for distributed screens.
For installation, check the screen pixel layout, receiving-card configuration and network connection. The two Gigabit LED outputs support a backup output. LoRa synchronization, environmental monitoring and automatic brightness adjustment require the corresponding external modules or sensors; 4G hardware is selected for the country of use.
Technical specifications
| Parameter | Specification |
|---|---|
| Model | Sysolution Y50 asynchronous LED display controller |
| Documented LED load | 920,000 pixels; listed resolution 1280 × 720 |
| Processor | Quad-core Cortex-A35, 1.5 GHz |
| Graphics | Mali-G31MP2 |
| Operating system | Android 9 |
| Memory | 1 GB LPDDR3 + 8 GB eMMC, as listed in the technical parameter table |
| Video decoding | 1080p hardware decoding |
| LED data outputs | 2 Gigabit Ethernet outputs; backup output supported |
| Communication | Ethernet, Wi-Fi and USB; cellular connection requires an optional module |
| Wi-Fi | IEEE 802.11b/g/n, 2.4 GHz; AP and Station modes |
| USB / audio | 1 USB 2.0 port; 1 stereo audio output |
| Serial interfaces | 1 RS485, 1 RS232 and 1 TTL serial port |
| Environmental data | External R68 eight-element sensor supported through RS485 |
| Brightness adjustment | Automatic adjustment with a matching brightness sensor |
| Multi-screen synchronization | External LoRa synchronization module supported |
| Timing | GPS timing and NTP automatic time calibration supported |
| Remote switching | Two control channels: screen switch and street light switch |
| Software | AIPS 4.0 cloud platform, LedOK Express for PC and LedOK Kit mobile app |
Product images and specification download
Download specification:
Sysolution Y50 asynchronous card supports network remote control Specification
Frequently asked questions
What size LED display can the Sysolution Y50 control?
The Y50 manual lists a load of 920,000 pixels and a 1280 × 720 display resolution. Its 1080p hardware decoding specification describes supported video decoding, not a 1920 × 1080 LED screen load.
Can I update the Y50 remotely without connecting a PC at the screen?
Yes. The Y50 supports remote program publishing and group control through the AIPS cloud platform. Ethernet and Wi-Fi are supported; mobile-network access requires the appropriate optional 4G module. LedOK Express and LedOK Kit provide PC and mobile management options.
Does every Y50 include 4G connectivity?
No. The manual lists a Y50-WIFI version without 4G and several regional cellular versions. Specify the installation country and check the required operator bands before ordering a cellular configuration.
Can multiple Y50 screens play content in sync?
The controller supports an external LoRa synchronization module for multi-screen playback. Confirm that the required module is included in the chosen configuration.
Can the Y50 display environmental readings and adjust brightness automatically?
It supports an external R68 eight-element environmental sensor over RS485. Automatic brightness adjustment requires a matching brightness sensor; these sensor functions should be planned with the appropriate accessories.
| Weight | 0.6 kg |
|---|
