P6.67 Outdoor LED Display Module, 320 × 160 mm, SMD3535
$ 16.20
This P6.67 outdoor module uses Kinglight SMD3535 LEDs on a 320 × 160 mm board. The listed supply voltage is 5 V and the power consumption is 30 W.
9994 in stock
For a new outdoor display, each module adds 48 pixel columns and 24 rows. The specifications below describe the SMD3535 listing. The linked sheet identifies a separate SMD2525 version with the same footprint and a different power rating.
Technical specifications
| Item | Specification | Remark |
| LED type | SMD3535 | |
| Pixel pitch | 6.67mm | |
| Pixel configuration | 1R1G1B | |
| Module Size | 320x160mm | |
| Module resolution | 48x24pixels | |
| Density | 22,497 pixels/㎡ | |
| Driving Mode | 1/6 duty | |
| Brightness | ≥5300CD/㎡ | |
| Viewing angle | H:120°,V:120° | |
| Best view distance | ≥6.5m | |
| Driving IC | General driver IC | |
| Working voltage | 5V | |
| Power consumption | 30W | |
| Weight | 0.6KG | |
| Protection grade | Front: IP65 | |
| Working Temperature | -20～60℃ | |
| HUB card | HUB75 |
Package and ordering information
Each module comes with an inter-module signal cable and a power cable for connection to the supply. Order all modules for one screen together so they come from the same production batch; different batches can vary in color and brightness. These modules are not supplied or supported as spare parts for existing older displays. Destination duties and customs clearance are the buyer’s responsibility.
Product documentation and photos
Download the module specification (PDF)
Frequently asked questions
How much power does the P6.67 SMD3535 board use?
The product table lists 30 W per module at 5 V. The 45 W maximum in the linked PDF applies to model P6.67-O6S-SMD2525-48×24.
Does the IP65 rating cover the rear?
The product table specifies IP65 for the front. Plan the rear enclosure around the installation requirements.
Which PDF matches my P6.67 module?
Read the LED package and full model number. The supplied document identifies SMD2525 on its cover, while this product lists SMD3535. Check those markings before using the document for electrical or optical specifications.
| Weight | 2 kg |
|---|
