MEAN WELL HLG-150H-12A 12V 12.5A 150W LED Driver
$ 36.00
The MEAN WELL HLG-150H-12A is a 12V, 12.5A, 150W LED driver with an IP65 metal housing. Built-in potentiometers adjust the voltage from 10.8–13.5V and current from 7.5–12.5A.
9600 in stock
The MEAN WELL HLG-150H-12A delivers a nominal 12V output at a rated 12.5A and 150W. It supports constant-voltage and constant-current operation for compatible LED loads. The A suffix identifies an IP65 model with voltage and current adjustment through built-in potentiometers.
HLG-150H-12A specifications
| Parameter | Specification |
|---|---|
| Rated DC voltage | 12V |
| Rated current | 12.5A |
| Rated power | 150W |
| Constant-current region | 6–12V |
| Voltage adjustment | 10.8–13.5V |
| Current adjustment | 7.5–12.5A |
| AC input | 90–305VAC, 47–63Hz |
| Typical efficiency | 91.5% |
| Ingress protection | IP65 (A type) |
| Dimensions (L × W × H) | 228 × 68 × 38.8mm |
| Working case temperature | −40 to +90°C; follow the output-load derating curves |
| Cooling | Fanless, free-air convection |
Values are taken from the 12V column and A-type function table of the original linked HLG-150H specification. Observe low-input-voltage and thermal derating.
Using the driver with a 12V LED load
Confirm that the LED equipment requires 12V and stays within the rated current and power. For constant-current operation, check the load voltage against the 6–12V region. A display or lighting product’s voltage requirement must be checked before connecting it; the driver is not suitable for every LED screen merely because it is an LED power supply.
Frequently asked questions
Does “12A” in HLG-150H-12A mean 12 amps?
No. The model code combines a 12V output designation with the A function suffix. The specified rated output current is 12.5A.
Can I adjust the HLG-150H-12A output?
Yes. The built-in voltage adjustment range is 10.8–13.5V, and the current adjustment range is 7.5–12.5A. Follow the connected load’s permitted settings.
Does HLG-150H-12A include external dimming?
This A-type model has built-in adjustment. External 3-in-1 dimming is offered on different suffix versions in the HLG-150H series.
Is this model IP65 or IP67?
HLG-150H-12A is the IP65 version. The retained PDF provides the suffix-specific function table, mechanical drawing and operating curves.
Product images and specification download
| Weight | 1.15 kg |
|---|
