Magnimage MIG-F4 4K Video Mosaic Box
$ 1,018.00
Magnimage MIG-F4 provides two DP and two HDMI inputs for four-output video wall mosaics. It supports 4K × 2K at 60 Hz 4:4:4 input, input backup and custom output resolutions.
4K mosaic processing for multiple screens
The Magnimage MIG-F4 series is a compact video splicing processor with two DP and two HDMI inputs. It can arrange a source across four outputs, with cropping and layer zoom for selecting the content shown on each screen.
Technical specifications
| Parameter | Specification |
|---|---|
| Model | MIG-F4 series |
| Inputs | 2 DP; 2 HDMI |
| Input formats | 4K × 2K at 60 Hz, 4:4:4; 8K × 1K at 60 Hz |
| Output options | 4 DVI or 4 HDMI; confirm the supplied configuration |
| Processing capacity | Up to 9 million pixels |
| Output resolution | Customizable |
| Signal configuration | EDID management; input backup |
| Control | PC software; Android app; Wi-Fi hotspot |
Screen layout and setup
Custom output resolutions accommodate screens of different sizes. Preset saving and recall simplify reuse of a layout, while synchronized multi-unit splicing and edge blending support larger installations.
Frequently asked questions
Does the MIG-F4 support 4K at 60 Hz?
Yes. A single input supports 4K × 2K at 60 Hz with 4:4:4 color sampling.
Does the MIG-F4 have DVI or HDMI outputs?
The series specification lists four DVI or four HDMI outputs. Confirm which output configuration is supplied before ordering.
How many DP and HDMI inputs are provided?
The MIG-F4 series lists two DP and two HDMI inputs.
Can I use screens with different resolutions?
Yes. Custom output resolution and image cropping allow the source to be arranged for screens of different sizes.
Does it support presets and backup?
Yes. It supports preset saving and recall, input backup and synchronized splicing across multiple units.
Product images and diagrams
Downloads
| Weight | 3 kg |
|---|
