Linsn RV216B LED Receiving Card with Dual Backup
$ 14.00
Linsn RV216B LED receiving card supports 32 RGB data groups, pixel brightness calibration, configuration readback and dual-card backup.
9988 in stock
The Linsn RV216B is a receiving card for LED display cabinets, with 32 groups of RGB data output and dual-card backup support. Pixel brightness calibration and single-card color-space conversion help configure cabinet output. Select the loading layout according to the LED module design.
Technical specifications
| Parameter | Specification |
|---|---|
| Model | RV216B |
| Data output | 32 RGB groups |
| Maximum listed load | 512 × 512 pixels; recommended load depends on screen design |
| Calibration | Pixel-by-pixel brightness; single-card color-space conversion |
| Configuration | Configuration file readback |
| Decoding | 138 and 595 serial decoding |
| Backup | Dual-card backup |
XLinsn Technology RV216B Receiving Card LED Display Specification
Frequently asked questions
What is the RV216B maximum pixel load?
The listed maximum is 512 × 512 pixels. Recommended loading depends on the design of the LED screen.
Does the RV216B support dual-card backup?
Yes. Dual-card backup is a listed function. The receiver configuration and cabinet wiring must support the intended backup arrangement.
Can the RV216B read back its configuration?
Yes. Configuration file readback is supported, which helps retain the settings used by an existing cabinet.
| Weight | 0.11 kg |
|---|
