Xixun M50B-D Standalone LAN LED Player Box
$ 58.00
Xixun M50B-D standalone LED player box with a 650,000-pixel Gigabit display output, separate LAN input, Wi-Fi and optional 4G. Supports stored programs, scheduled control and USB content import.
9998 in stock
M50B-D player for local and networked LED signs
The Xixun M50B-D is a standalone LAN player box with Android-based program playback. Its LED output serves up to 650,000 pixels, while separate LAN, Wi-Fi and USB communication options support content publishing and display management.
Choose the optional cellular and sensor configuration for the installation. Standard loading limits, the separately stated extended-width mode and video decoding capability are different specifications and should be checked individually.
Technical specifications
| Parameter | Specification |
|---|---|
| Model | Xixun / Sysolution M50B-D standalone LAN LED player box |
| LED output | 1 Gigabit Ethernet display output; 650,000 pixels |
| Standard dimension limits | Maximum width 1,920; maximum height 1,920 pixels, subject to total pixel capacity |
| Extended-width statement | The PDF separately lists up to 7,680 width and 1,920 height under a “discount” condition without defining it; confirm the applicable loading mode |
| LAN input | 100 Mbit/s network input, separate from the Gigabit LED output |
| CPU / GPU | Quad-core Cortex-A35 at 1.5 GHz / Mali-G31MP2 |
| Memory / storage | 1 GB LPDDR3 / 8 GB eMMC; original listing states 4 GB user-available storage |
| Operating system | Android 9.0 |
| Video decoding | 1080p hardware decoding |
| Wi-Fi | IEEE 802.11b/g/n, 2.4 GHz; AP and Station modes |
| Communication | LAN, Wi-Fi and USB drive; optional 4G module |
| Cellular variants | Base M50B-D without 4G; CH, NA, EU, LA and G modem variants listed. Confirm bands for the deployment country. |
| USB / audio | 1 USB 2.0 port; USB program import/playback and camera support; stereo audio output |
| Serial interfaces | 1 RS485, 1 RS232 and 1 TTL port |
| Positioning and timing | External GNSS GPS/BeiDou/GLONASS module support; GPS and NTP time synchronization |
| Sensor support | Automatic brightness with a matching sensor; R68 environmental sensor via RS485 |
| Program management | Playlists, scheduled switching, volume and brightness management; local web publishing and remote screen management |
| Software | LedOK Express PC software and LedOK Kit mobile app |
| Power supply | 12 V; independent 12 V / 3 A or higher supply recommended |
| Current / power entries | 0.9 A working current, 3 A maximum; PDF separately lists 10 W maximum working power. Confirm these entries for the supplied configuration. |
| Operating conditions | −30 to +75°C; 10–90% RH, non-condensing |
| Storage temperature | −40 to 75°C; recommended 5 to 35°C |
Product images and specification download
Xixun M50B-D LED Display Control Card Specification
Frequently asked questions
What is the LED loading limit of the M50B-D?
The specification lists 650,000 pixels on one Ethernet display output, with standard maximum width and height of 1,920 pixels each. These are separate dimension limits and do not mean that a 1,920 × 1,920 screen is supported.
Can the M50B-D control a 7,680-pixel-wide screen?
The PDF includes a separate extended-width statement of 7,680 pixels under a “discount” condition, but it does not define that mode or its reduced loading. Confirm the intended resolution and configuration before relying on this value.
Are the two network connections interchangeable?
No. The interface table identifies a Gigabit display output and a separate 100 Mbit/s LAN input. Use each port for its stated purpose.
Does every M50B-D include 4G and automatic brightness?
The base M50B-D is listed without 4G; a cellular modem is optional and region-dependent. Automatic brightness requires a matching external brightness sensor. Confirm both options when selecting the configuration.
How do I publish and schedule content?
The specification lists LedOK Express for PC, LedOK Kit for mobile devices and local web publishing. Playlists, scheduled switching, volume and brightness can be managed through the control system. USB program import and playback are also supported.
| Weight | 6 kg |
|---|
