G-Energy JPS300P-A5.0V 5 V 60 A LED Display Power Supply
$ 30.00
This self-cooled G-Energy supply provides a constant 5 V output at up to 60 A. Maximum output power is 300 W.
9871 in stock
The JPS300P-A5.0V accepts AC feeds from 100 to 240 V. For an enclosed cabinet, check the working temperature as well as the total current needed by the display.
Product details
| Parameter | Specification |
|---|---|
| Model | JPS300P-A5.0V |
| Output | 5 V DC, 0–60 A; 300 W maximum |
| AC input | 100–240 V, 47–63 Hz |
| Ripple and noise | ≤200 mV |
| Efficiency | ≥88% |
| Cooling | Self-cooling |
| Working temperature | −30 to +50 °C |
| Storage temperature | −40 to +80 °C |
| Power factor | 0.95 at 230 V AC |
| Leakage current | Less than 1 mA at 230 V input |
| Insulation voltage | Input–output: 3.0 kV AC; input–FG: 1.5 kV AC; output–FG: 0.5 kV AC |
| Protection | Input undervoltage, overload and short circuit |
| Safety standards listed | GB4943, EN60950 |
Download the product specification (PDF)
Frequently asked questions
What output current can the 5 V version supply?
The specified current range is 0–60 A, with a maximum output of 300 W.
How hot can the cabinet get during operation?
The stated working range ends at +50 °C. The higher +80 °C limit applies only to storage.
What are the efficiency and ripple ratings?
The model table specifies efficiency of at least 88% and ripple and noise no greater than 200 mV.
| Weight | 0.8 kg |
|---|
