CZCL A-200AF-5 Low-Profile 5 V 40 A Supply for Rental LED Cabinets
$ 8.80
The A-200AF-5 is a low-profile 5 V, 40 A supply listed for compact die-cast LED rental cabinets. Its maximum output power is 200 W.
10000 in stock
Check the AC feed and the clearance around the unit before fitting it in a cabinet. This listing specifies 200–240 V AC at 47–63 Hz for the input.
Product specifications
| Parameter | Specification |
|---|---|
| Model | CZCL A-200AF-5 |
| Output | 5 V DC, 40 A |
| Maximum output power | 200 W |
| Input | 200–240 V AC, 47–63 Hz |
| Operating temperature | −30 to +60 °C |
| Storage | −40 to +100 °C, 20–95% RH |
| Power factor | 0.50 at 230 V AC |
| Leakage current | 0.30 mA at 230 V AC |
| Protection | Undervoltage, overload, short circuit |
| Insulation voltage | Input–output 3.0 kV AC, input–FG 1.5 kV AC, output–FG 0.5 kV AC |
Frequently asked questions
Which mains feed does this A-200AF-5 listing specify?
The input is 200–240 V AC at 47–63 Hz. Verify the corresponding marking on the replacement unit.
What conditions apply to the 0.30 mA leakage figure?
The listed leakage current is 0.30 mA at an input of 230 V AC.
Can I use the storage temperature when sizing cabinet ventilation?
Use the operating range of −30 to +60 °C for an energized supply. The storage range applies to the unit while stored.
| Weight | 0.6 kg |
|---|
