Huidu HD-S107 Brightness Sensor for LED Display Controllers
$ 13.60
HD-S107 brightness sensor connects to a compatible Huidu LED control system to adjust screen brightness as ambient light changes. Listed parameters include a 1%–100% brightness range and 1500 mm standard wiring length.
9997 in stock
Huidu HD-S107 Ambient Brightness Sensor
The HD-S107 senses surrounding brightness and connects to the LED display control system so screen brightness can change with the environment. It adds ambient-light sensing and automatic brightness adjustment to compatible full-color Huidu controllers.
Controller Compatibility
This product is listed for the C16C control card. Its original compatibility information also names HD-D15, D35, C15, C35, A30, A30+ and A60X controllers. Check the exact controller model and sensor connection before installation.
| Parameter | Specification |
|---|---|
| Sensor type | Ambient brightness sensor |
| Listed brightness range | 1%–100% |
| Working temperature | −25°C to 85°C |
| Sensitivity levels | High, medium and low |
| Listed data-acquisition intervals | 5 s, 10 s and 15 s |
| Standard wiring length | 1500 mm |
| Listed controllers | C16C; HD-D15, D35, C15, C35, A30, A30+ and A60X |
The brightness range is expressed as a percentage in the product information; it is not a lux measurement range. Confirm the controller settings required for automatic adjustment in your installation.
Product Image
Specification Download
Download the Huidu HD-S107 brightness sensor specification (PDF)
Frequently Asked Questions
What does the HD-S107 brightness sensor do?
It senses ambient brightness and works with a compatible LED control system to adjust screen brightness as the surrounding light changes.
Is the HD-S107 listed for the Huidu C16C?
Yes. C16C is identified in the product listing. The compatibility information also names HD-D15, D35, C15, C35, A30, A30+ and A60X; confirm the sensor connection for the exact controller.
What is the HD-S107 brightness range?
The listed brightness range is 1%–100%. This percentage should not be interpreted as a lux measurement range.
How long is the standard HD-S107 cable?
The listed standard wiring length is 1500 mm.
How often does the HD-S107 collect brightness data?
The technical information lists 5-second, 10-second and 15-second data-acquisition intervals, together with high, medium and low sensitivity levels.
