Huidu HD-VP620 LED Video Processor – 6 Outputs, PIP/POP
Original price was: $ 420.00.$ 372.00Current price is: $ 372.00.
HD-VP620 video processor and LED sender with six Gigabit outputs, five video input channels and dual-picture PIP/POP. Supports panel-based cabinet setup and USB configuration through HDSet; see the loading-capacity note before sizing a screen.
10000 in stock
Huidu HD-VP620 Video Processor and LED Sender
The HD-VP620 combines video processing and LED sending through six Gigabit Ethernet outputs. Its five digital and analog input channels support source switching, while two-picture PIP and POP layouts allow content to be arranged within the LED display.
Configuration and Monitoring
Set cabinet connection parameters directly from the panel using the connection-setting function, or connect a PC by USB Type-B for HDSet configuration and upgrades. Navigation Settings assist setup, and scene presets can be saved and recalled. The HDMI monitor connection outputs a synchronous 1920 × 1080 at 60 Hz signal to an external LCD.
| Parameter | Specification |
|---|---|
| LED output ports | 6 × Gigabit Ethernet |
| Pixel capacity — source discrepancy | Feature list: 3.9 million pixels; output table: 5.2 million pixels. Confirm before screen sizing. |
| Listed dimension limits | Maximum width 8000 pixels; maximum height 3840 pixels |
| Video input channels | 5: DVI, HDMI, DP, VGA and EXT |
| DVI input | DVI-I; DVI 1.0; PC up to 1920 × 1080; HD up to 1080p |
| HDMI input | HDMI-A; HDMI 2.0 backward compatible; up to 3840 × 2160 at 60 Hz |
| DP input | DP 1.2 backward compatible; up to 3840 × 2160 at 60 Hz |
| VGA input | DB15; up to 1920 × 1080p at 60 Hz |
| EXT input | DVI or SDI; standard configuration is DVI |
| Display layout | Dual-picture PIP and POP |
| Audio | 1 × 3.5 mm input; 1 × 3.5 mm output |
| Monitor output | HDMI, 1920 × 1080 at 60 Hz |
| PC setup | USB Type-B; HDSet software |
| Wi-Fi mobile app | Marked as under development in the supplied specification |
| Power input | 100–240 V AC, 50/60 Hz |
| Power consumption | ≤75 W |
| Weight | ≤3.6 kg |
| Dimensions (L × W × H) | 482 × 302.8 × 65.5 mm |
| Chassis | 1.5U standard industrial chassis |
Loading-Capacity Clarification
The supplied HD-VP620 PDF states 3.9 million pixels in its feature list on page 3, but 5.2 million pixels in the output table on page 5. These entries conflict. Confirm the supported total load for the actual unit before ordering for a particular screen size. The listed maximum width and height are separate limits and must not be multiplied to infer capacity.
Specification Download
Download the Huidu HD-VP620 specification (PDF)
Frequently Asked Questions
How many LED outputs does the HD-VP620 have?
It provides six Gigabit Ethernet outputs for the LED receiving-card system.
What is the VP620 maximum pixel load?
The supplied document contains conflicting figures: 3.9 million in the feature list and 5.2 million in the output table. Confirm the capacity for the actual unit before sizing the display.
Can the VP620 accept a 4K60 source?
The listed HDMI 2.0 and DP 1.2 inputs support up to 3840 × 2160 at 60 Hz. Input resolution is separate from the LED output loading limit.
Can I set up cabinets from the front panel?
Yes. The connection-setting function configures cabinet connection parameters through panel buttons. HDSet over USB provides a PC-based option.
Is the Wi-Fi app available?
The supplied specification labels the Wi-Fi mobile app as under development. Check availability for the unit before relying on wireless app control.
