Huidu HDP901 LED Video Processor & Splicer with PIP
Original price was: $ 672.00.$ 460.00Current price is: $ 460.00.
Huidu HDP901 is an LED video processor and splicer with 5.3 million pixel custom-resolution output, PIP and chroma key. It supports two-channel splicing, a monitoring output, and an optional SDI input.
10000 in stock
HDP901 video processing and LED screen splicing
The Huidu HDP901 combines source switching, image processing and splicing for LED display systems. It supports seamless channel switching, picture-in-picture (PIP) and chroma key, with two splicing channels and one monitoring output. Multiple processors can be used for multi-machine splicing.
Technical specifications
| Parameter | Specification |
|---|---|
| Custom-resolution output | 5.3 million pixels at 60 Hz, across A and B outputs |
| Video inputs | 4 × composite video, 2 × VGA, 2 × DVI, 2 × HDMI; 1 × SDI optional |
| DVI / VGA input | VESA formats up to 1920 × 1080 at 60 Hz |
| Video outputs | 5 × DVI (4 program outputs and 1 monitor output), 1 × VGA; optional SDI loop output |
| Splicing | Two-channel splicing; multi-machine splicing supported |
| Image functions | PIP, chroma key, partial/full-screen switching |
| Operation | Scene preset save/recall, engineering lock, PC control and timing switch |
| Sending-card installation | Four internal installation positions |
| Chassis size | 483 × 280 × 69 mm |
| Weight | 4 kg |
Output-resolution note: the V1.2 feature list gives 7840 × 640 at 60 Hz and 4608 × 1152 at 60 Hz, while its output table lists 7680 × 640 at 60 Hz among the custom A+B formats. These conflicting wide-format values are not interchangeable; verify the required mode before specifying a wide screen.
Input selection and installation
The advertised 11-input count includes the optional SDI input. Composite video and VGA are analog inputs, so the full set should not be described as eleven digital inputs. Confirm the SDI configuration if it is needed for your source equipment.
Four sending-card installation positions provide space for integration. This is a mounting provision, not confirmation that four sending cards are supplied. Check the order configuration against the sending cards and receiving cards used in the display.
HDP901 demonstration video
Product photo
PDF downloads
Download HDP901 specification V1.2
Download HDP901 user manual V1.2
Frequently Asked Questions
Does the Huidu HDP901 support PIP and chroma key?
Yes. Picture-in-picture and chroma key are listed features, along with partial/full-screen switching.
How many video inputs does the HDP901 have?
The specification lists four composite, two VGA, two DVI and two HDMI inputs, plus one optional SDI input. The eleven-input total includes the optional SDI configuration.
What is the HDP901 custom output capacity?
The V1.2 specification lists 5.3 million pixels at 60 Hz across the A and B outputs. Check the resolution note above for the conflicting wide-format entries.
Can the HDP901 splice screens and provide monitoring?
It supports two-channel splicing, one monitoring output and multi-machine splicing. Consult the user manual for connection and configuration details.
Are four LED sending cards included?
The specification identifies four internal installation positions. It does not establish which sending cards are included in an order; confirm the supplied configuration before purchase.
