VDWall DS4-8 DVI Splitter – 4 Inputs, 8 Outputs
$ 240.00
Distribute four DVI sources through four independent 1-input/2-output channels. The VDWall DS4-8 provides eight DVI outputs, supports up to 1920 × 1200 at 60Hz and includes signal equalization.
10000 in stock
Four independent DVI distribution channels
The VDWall DS4-8 DVI splitter distributes each of four DVI inputs to a pair of outputs. It is suitable for DVI signal distribution in LED display systems that use multiple sending cards. Its four channels operate independently.
Technical specifications
| Parameter | Specification |
|---|---|
| DVI inputs | 4 |
| DVI outputs | 8 |
| Channel arrangement | 4 independent 1-input/2-output distributors |
| Maximum listed resolution | 1920 × 1200 at 60Hz |
| Signal enhancement | Equalization supported |
| Connector | 24+5 DVI-I |
| Signal amplitude / impedance | TMDS 0.5 V p-p / 75Ω |
Frequently asked questions
Does the DS4-8 split one input to all eight outputs?
It has four independent channels. Each input feeds two outputs; the unit is not described as a single 1-in/8-out splitter.
What resolution does the DS4-8 support?
The listed maximum is 1920 × 1200 at 60Hz. Match the source timing and downstream equipment to the supported DVI formats.
Is the DS4-8 a video processor or a DVI distributor?
It is a DVI distributor for signal splitting. Use the video processor in your system for functions such as scaling and screen layout.
Where can I find the DS4-8 connection information?
The retained specification and user manual downloads below provide the connection diagrams and operating details.
Product image and PDF downloads
VDWALL DS4-8 DVI Distributor Specification
VDWALL DS4-8 spliter User Manual
| Weight | 3 kg |
|---|
