Magnimage LED-550D LED-550DS large LED sceen Video Processor

Magnimage 550D large LED sceen Video Processor series developed for the large screen display system, adopted the top image processing chips, internal 12 bits processing, with clearer images and richer colors. It supports the seamless switch between different input signal sources and picture in picture function.
$559.00
More Information
Weight(kg) 8.50 kgs
Manufacturer Magnimage
Availability: In stock
SKU
Magnimage-LED-550D

Magnimage LED-550D large LED sceen Video Processor Description:

Magnimage LED-550D large LED sceen Video Processor is a high performance full color LED video processor which has 16 switching effects including fade in/ fade out, switch and so on. It can customize any DVI input resolution improve the system stability, customized output resolution based on real specification of LED screen to reach the effect of pixel to pixel display. Intelligent seamless splicing technology of super size LED screen with multi- sending card image splicing. The unique synchronous follow-up technology ensure the image is fluent and no dislocation and trailing when it's high speed action. LED-550D is suitable for stage show, conference, large events, exhibition, command, and surveillance center.



Magnimage LED-550D large LED sceen Video Processor Functures:

Seamless splicing
Seamless Switching
Part/Full
Customized DVI input resolution
Fade in/fade out
Hot backup
Dual pictures
Various test graphic cards
User-defined resolution
Accurate brightness control
More freindly interface
User-defined resolution
Image freeze/Test overlay
Dual image
Template setting/multi-machine cascade
Text overlay
Accurate brightness control
Hot back
User friendly operation
Single machine maximum output resolution:2560×816/60Hz 2304×1152/60Hz 1536×1536/60Hz



Magnimage LED-550D large LED sceen Video Processor Specification:

 Inputs

Ports No. Resolution Specification
AV 2 PAL NTSC SECAM
VGA 2 VESA
DVI 1 VESA(1080i)
HDMI 1 HDMI 1.3
SDI* 1 3G SDI

 Outputs

Ports No. Resolution Specification
DVI loop 1 Same as DVI input
SDI loop* 1 3G SDI
VGA 1

1024×768/60Hz/75Hz/85Hz/100Hz/120Hz

1280×1024/60Hz   1440×900/60Hz

1680×1050/60Hz   1600×1200/60Hz

1600×1200/60Hz-Reduced

1920×1080/60Hz/50Hz

2560×816/60Hz    1920×1200/60Hz

2048×640/60Hz    2560×816/60Hz

2304×1152/60Hz      2048×1152/60Hz

1024×1280/60Hz  1536×1536/60Hz

Customized output resolution:

Horizontal Max Resolution 3840pixel ; Min 640

Vertical Resolution: Max 1920; Min 480

DVI 2

* Optional

 Cosole specification

Power supply 100~240 AC 50/60Hz
Power consumption 25W
Operation temperature 0~45℃
Product dimension(LWH) 483.0×288.0×54.5mm
Packing dimension(LWH) 555.0×395.0×125.0mm
N.W. 2.6kg
G.W. 4.1kg

Magnimage LED-550D LED-550DS large LED sceen Video Processor

Magnimage LED-550D LED-550DS large LED sceen Video Processor

Magnimage LED-550D LED-550DS large LED sceen Video Processor

Download Specification

Magnimage LED-550D Video Processor Specification
