Mooncell MVB16S 16-Port 4K LED Video Processor
$ 1,403.00
Mooncell MVB16S combines video processing and LED sending with 16 Gigabit outputs and 10.4-million-pixel total loading. Supports HDMI 2.0 and DP 1.2 input up to 4096 × 2160 at 60 Hz and eight display windows.
888 in stock
MVB16S integrated video processing and LED sending
The Mooncell MVB16S combines source selection, splicing, scaling and LED output in one processor. Its 16 Gigabit outputs serve a total of 10.4 million pixels, while up to eight adjustable windows provide flexible source layouts.
Use HDMI 2.0 or DP 1.2 for the specified 4K60 input capability. The maximum screen width and height are independent limits, and the reserved 3D-SYNC connection is not an advertised active 3D function.
Technical specifications
| Parameter | Specification |
|---|---|
| Model / document | Mooncell MVB16S; V3.5 specification |
| LED output ports | 16 Gigabit Ethernet ports |
| Total loading | 10.4 million pixels |
| Per-port loading | 650,000 pixels |
| Maximum width / height | 30,720 pixels / 30,720 pixels as separate limits, within total loading |
| HDMI 2.0 input | 1; up to 4096 × 2160 at 60 Hz |
| DisplayPort input | 1 DP 1.2; up to 4096 × 2160 at 60 Hz |
| HDMI 1.3 inputs | 3; up to 1920 × 1200 at 60 Hz |
| DVI input | 1; up to 1920 × 1200 at 60 Hz, HDCP supported |
| Multi-window display | Up to 8 simultaneous windows with adjustable position and size |
| Video functions | Source switching, image splicing, scaling and EDID management |
| Control interfaces | 1 × 100 Mbit/s RJ45 control port; 1 × RS232 |
| 3D-SYNC | Reserved interface; the specification does not establish an active 3D function |
| Front controls | LCD, rotary menu control, MENU/ESC/BLACK/LOCK buttons and numeric scene recall |
| AC input / rated power | 100–240 V AC, 50/60 Hz / 36 W |
| Operating conditions | −20 to 70°C; 10–80% RH, non-condensing |
| Chassis dimensions / net weight | 472 × 290 × 64 mm / 3.45 kg |
Product images and specification download
Full-Color-MVB16S-Monncell-2 In1-LED-video-processor-Specification
Frequently asked questions
Can the MVB16S drive a 30,720 × 30,720 screen?
No. Width and height are separate maximum dimension limits. The complete screen must remain within the 10.4-million-pixel total and the loading limits of the 16 Ethernet outputs.
Which inputs accept 4K at 60 Hz?
The HDMI 2.0 and DP 1.2 inputs are each specified for up to 4096 × 2160 at 60 Hz. The three HDMI 1.3 inputs and DVI input are listed at up to 1920 × 1200 at 60 Hz.
How many source windows can be displayed?
The processor supports up to eight simultaneous windows. Their positions and sizes can be adjusted, with image splicing and scaling to match the screen layout.
Is the RJ45 control port an additional LED output?
No. The 100 Mbit/s RJ45 control port manages the processor. The 16 Gigabit Ethernet output ports carry the LED display data.
Does the 3D-SYNC connector mean 3D playback is supported?
The specification labels 3D-SYNC as reserved. It should not be treated as confirmation of an available 3D playback feature.
